Model NO.:
VHD-JX1700
Price:
USD 268.00-288.00 / set
Minimum order quantity:
1 set
Supply Ability:
500.0 set / Day
Country of Origin:
Shenzhen
Quantity:
  • Product Name:True 4K Ultra HD Wireless Camera
  • Video Format:4K@30fps/25fps
  • Sensor:1/2.5", CMOS, Effective Pixel: 8M
  • Scanning Mode:Progressive
  • Lens:Focus: f=7.35mm; f=3.5mm; f=2.8mm
  • Input/Output Interface:RJ45; USB2.0
  • Input Voltage:DC 12V / PoE (802.3af)
  • Autofocus:Support
  • Size:194mmx34mmx42mm (without bracket)
  • MTBF:30000h
  • Simultaneous Interpretation:No
  • Type:Video Conference System
  • Function:Video Conference
  • Place of Origin:CN;GUA
  • Brand Name:VHD
  • Model Number:VHD-JX1700
Product Description
Main Features
4K Ultra HD:4K(3840x2160)@30fps/25fps, downward compatible with 1080P, 720P, etc.
High Efficient Teaching Traking(Optional)
AF: Auto Focus Lens, 46°/84°/120° field of view, support EPTZ.
Built-in Microphone
Local Storage
WDR (wide dynamic range): Deliver easy availability for various lighting environments in the most harsh conditions.
Low Light: CMOS sensor, 2D/3D noise reduction algorithm, SNR of 55dB.
PoE support
Specifications
Camera
Sensor
1/2.7'', CMOS, Effective Pixel: 8.51M
Scanning Mode
Progressive
Lens Mount
M12
Lens 1
Focus: f=7.35mm, FOV: 46°
Lens 2(Default)
Focus: f=3.5mm, FOV: 84°
Lens 1
Focus: f=2.8mm, FOV: 120°
Autofocus
Support
Minimal Illumination
0.05 Lux @ (F1.8, AGC ON)
Shutter
1/30s ~ 1/10000s
White Balance
Auto, Indoor, Outdoor, One Push, Manual
Digital Noise Reduction
2D, 3D digital noise reduction
Camera bracket
Optional
Backlight Compensation
Support
PoE
Support
Local Storage
Support
Auto Tracking Function
Teacher mode / Student mode (optional)
Network Features
Video Compression
H.265 / H.264 / MJEPG
Video Stream
Main Stream, Sub Stream
Main Stream Resolution
3840x2160, 1920x1080, 1280x720, 1024x576 etc.
Sub Stream Resolution
1920x1080, 720x576, 720x480, 320x240 etc.
Video Bit Rate
128Kbps ~ 20480Kbps
Bit Rate Type
Variable Rate, Fixed Rate
Frame Rate
50Hz: 1fps ~ 50fps, 60Hz: 1fps ~ 60fps
Audio Compression
AAC
Audio Bit Rate
96Kbps, 128Kbps, 256Kbps
Support protocols
TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc.
Input/Output Interface
Network Interface
1xRJ45: 10M/100M/1000M Ethernet Interface
1xWireless Wi-Fi (optional)
USB Interface
1xUSB 2.0: Type A, famale
General specification
Input Voltage
DC 12V / PoE (802.3af)
Operating Temperature
-10°C ~ 40°C (14°F ~ 104°F)
Storage Temperature
-40°C ~ 60°C (-40°F ~ 140°F)
Size
194mm x 34mm x 42mm (without bracket)
MTBF
30000h
